Mini CNC Lathes With Variable Speed

The Mini CNC Lathes With Variable Speed will be a good choice for fully automatic production. It uses a fully automatic feeding structure, very well for processing light turning products with a diameter of less than 40mm.

Model:TCK40-240L

Send Inquiry

Product Description

The Detailed Product Introduction of Mini CNC Lathes With Variable Speed

TCK40-240L mini CNC lathes with variable speed suitable for the processing of light cutting products with a diameter of less than 40mm. With automatic feeding mechanism, the product can be fully automatic production.

The Standard Configuration on Mini CNC Lathes With Variable Speed

Spindle：Spindle unit
System：Wind 2000TCEV（Standard）
GSK（Optional）
KND（Optional）
Inverter：SINEE
Linear Guide：CSK
Bearing：HRB
Ball Screw：QIJIAN/QIXUAN
Motor：Servomotor

The Parameter On Mini CNC Lathes With Variable Speed

		Unit	TCK40-240L			Unit	TCK40-240L
Production Capability	Max. swing over bed	mm	φ210	Stroke	X-axis max. trave	mm	240
	Max. swing over cross slide	mm	φ120	Stroke	Z-axis max. trave	mm	240
	Processing length	mm	240	Motor	Servomotor	kw	3.7
	Dia. of the spindle hole	mm	φ40	Other	Clamping mode	N/A	Hydraulic clamping
Spindle	Jig	N/A	Collet/Chuck		Tool holde	N/A	Cutter arrangement
	Speed range	Rpm	100-4000		Tool size	mm	20
	End specification	N/A			Number of tool loaded	pcs	6
Feeding	X-axis fast moving speed	m/min	28m		Overall dimensions(LWH)	mm
Feeding	Z-axis fast moving speed	m/min	28m		Height(Base to spindle)	mm	1010
Accuracy	X/Z axis repeated positioning accuracy	mm	0.005		N.W	mm

Features On Mini CNC Lathes With Variable Speed

1. Compact internal body structure, high rigidity, and vibration resistance.
2. Inclined body design will be much easier for scrap removal.
3. High processing efficiency, full automatic processing

Finished products
